1. What is the accuracy level of vortex flowmeters according to national standards?

The accuracy level of vortex flowmeters in the tracking range follows national standards such as GB/T 32201-201

5, JJG 1029-2007, etc., and is classified according to the maximum relative error. Shen Luan Industry commonly uses levels below 1.0. 1. According to Chinas specifications for vortex flowmeters, the main national standards include: • GB/T 32201-2015 (Verification Regulations for Gas Flowmeters) • JJG 1029-2007 (Special Verification Regulations for Vortex Flowmeters) • JB/T 9249 (Technical Specification for Sensors in the Mechanical Industry) Precision level classification is determined based on the maximum relative percentage error, and the system is divided into three categories: - Level 1 standard: 0.00

5, 0.0

2, 0.05 (laboratory level) - Level 2 standard: 0.

1, 0.

2, 0.3

5, 0.5 (process detection level) - Industrial application

1.0, 1.

5, 2.

5, State Circle 4.0 (conventional working condition level) 3 Error control requirements take the commonly used 1.0 level instrument in industry as an example: - Allowable ± 2% deviation below the boundary flow point - Restricted within ± 1% above the boundary flow point. Higher level 0.5 level instruments need to control an error of ± 0.25% in the range of 20% -100%

4. Core quality control indicators - Repeatability error should be ≤ 1/3 of the maximum allowable deviation - Dynamic compensation requirements: Deviation of viscosity fluctuation ± 20% should be ≤ ± 0.15%, temperature coefficient ± 0.01% FS/℃, pressure compensation accuracy ± 0.005% FS/kPa

2. Straight pipe section requirements for flow meters

>GB 50093-2002 Automation Instrument Engineering Construction and Acceptance Specification for Flow Meter Upstream and Downstream The usual requirements for straight pipe sections are as follows: - rotor flowmeter, upstream not less than 0-5 times the pipe diameter, downstream no requirements; ——Target flowmeter, with an upstream diameter not less than 5 times the pipe diameter and a downstream diameter not less than 3 times the pipe diameter; ——Turbine flowmeter, with an upstream diameter not less than 5-20 times the pipe diameter and a downstream diameter not less than 3-10 times the pipe diameter; ——Vortex flowmeter, with an upstream diameter not less than 10-40 times the pipe diameter and a downstream diameter not less than 5 times the pipe diameter; ——Electromagnetic flowmeter, with upstream diameter not less than 5-10 times the pipe diameter and downstream diameter not less than 0-5 times the pipe diameter; ——Ultrasonic flowmeter, with an upstream diameter not less than 10-50 times the pipe diameter and a downstream diameter not less than 5 times the pipe diameter; ——Positive displacement flowmeter, no requirements; ——Orifice plate, upstream not less than 5-80 times the pipe diameter, downstream not less than 2-8 times the pipe diameter; ——Nozzle, with an upstream diameter not less than 5-80 times the pipe diameter and a downstream diameter not less than 4 times the pipe diameter; ——Venturi tube, bent tube, wedge-shaped tube, upstream not less than 5-30 times the pipe diameter, downstream not less than 4 times the pipe diameter; ——Uniformity tube, with an upstream diameter not less than 3-25 times the pipe diameter and a downstream diameter not less than 2-4 times the pipe diameter. Additional information: Flow met
