Quick Answer: Silver Automation Instruments supplies professional anemometer and HVAC CFM meters for duct balancing, cleanroom validation, fume hood checks, and filter monitoring. These handheld tools measure air velocity in m/s or ft/min, calculate CFM when you enter duct size, and log data for reports. Send your duct width, duct height, velocity range, and whether you need data logging to get a quote with lead time.
HVAC commissioning crews use CFM meters to confirm supply and return airflow after damper adjustment. Cleanroom supervisors in Singapore and Penang check air change rates with hot wire anemometers. Food plants in Australia record hood face velocity during HACCP audits. A water treatment plant in Dubai may verify cooling tower airflow to prevent pump cavitation. We have seen these checks fail because the instrument was not calibrated or the wrong sensor type was used.
In practice, most engineers skip the sensor selection step and buy the cheapest vane meter. Then they get unstable readings in cleanrooms below 0.5 m/s. For low velocity, a hot wire sensor works better.
Hot wire anemometers cover 0.2 to 25 m/s. They are sensitive and fast for cleanrooms, laminar flow hoods, and indoor air quality checks. Vane probes handle 0.5 to 35 m/s and survive dusty HVAC ducts better. Pitot tubes reach 2 to 80 m/s and are used for exhaust stacks and industrial ventilation. For permanent airflow monitoring, a fixed thermal mass flow meter from Silver Instruments can output 4-20 mA HART to the BMS or PLC.
Do not use a handheld hot wire meter in compressed air above 2 bar. Use an insertion thermal mass flow meter for compressed air at 6 to 10 bar. We offer DN15 to DN50 insertion probes for this job.
Tell us the duct width and height in mm or inches. Give the expected velocity range and air temperature. For outdoor work in Saudi Arabia or Qatar, specify 60 °C ambient rating. For fume hood checks, a range of 0 to 5 m/s gives better resolution at low flow. For cooling tower air, a rugged vane probe with a 1 m extension is common. We can also add relative humidity sensors for environmental monitoring.
One customer in Vietnam asked for a CFM meter for a spray booth in a furniture factory. The requirement was 0.3 to 1.5 m/s face velocity with data storage for 12 hours. A hot wire meter with a 99 point memory was the right match. This is a typical application for small and medium manufacturers in Southeast Asia.
Measure the duct cross section at a straight section, not near elbows or dampers. Take a multi point traverse if the duct is larger than 300 mm. Let the meter stabilize for 10 seconds at each point. The meter averages the values and displays CFM. For a rectangular duct 600 mm by 400 mm at 3 m/s average velocity, airflow is about 2592 m3/h. This is a fast check before you sign off a balancing report.
Q: What is the difference between an anemometer and an HVAC CFM meter?
An anemometer reads air velocity. A CFM meter uses duct area to convert velocity into airflow volume. Many Silver Instruments handheld units do both tasks.
Q: Can this tool measure compressed air?
No. Handheld anemometers are not rated for compressed air above 2 bar. Use a thermal mass flow meter with an insertion probe for 6 to 10 bar compressed air lines.
Q: How do I measure CFM in a rectangular duct?
Enter the duct width and height in the meter. Take a traverse grid reading at multiple points. The device averages the velocity and calculates CFM from the area.
Q: What accuracy should I expect?
For hot wire units from Silver Instruments, accuracy is typically ±3 percent of reading plus 0.1 m/s. Vane probes are around ±2 percent of full scale.
Q: Do you supply calibration certificates?
Yes. We can arrange ISO 17025 or NIST traceable calibration certificates from our partner lab. Tell us the certificate requirement with your inquiry.
Send us your duct size in mm, expected air velocity range in m/s or ft/min, air temperature in °C, and whether you need data logging or a 4-20 mA output. Call Silver Instruments at +86-25-68650347, message us on WhatsApp at +86-25-52155837, or add our WeChat at +86 15365082610. We will reply with model options, price in USD, and delivery time to your nearest port.
You can also visit flow-meter.com.au for the full airflow instrument and thermal mass flow meter range.
